Cam Gear Lock Tool

When I had to do some engine work on the minivan, I was able to get a tool to lock the camshaft gears/sprockets/phasers in place so that everything would stay at top-dead center while I unbolted things.

Like this:

image of an cam gear sprocket holding tool

That’s for the Dodge 3.6L engine, which was in a bunch of vehicles for a long time, so it has good support from a variety of sources.

But now I’m doing a bunch of work on my car with a Chrysler 2.4L engine, from the early 2000s, used in Neons and PT Cruisers and some other things. It also uses the same cam sprockets (simple gears, no phasers) as the 2.0L, so this would work for that too.

Anyway, I was looking for a similar tool to hold the camshafts in place so I could do things like unbolt the crankshaft pulley and unbolt the camshafts themselves without rotating the engine.

But unlike the many options for the 3.6L tool, I found nothing for the 2.4/2.0 engine. There were some references to a prybar-type tool which is supposed to be the official way of holding the car gear in place, but I didn’t find a source to buy one. And even if I did, my guess is it would have been more than I wanted to pay.

I wanted a simple insert with teeth, like the 3.6 thingy. And it just so happens that my son got a 3D printer last month. So I decided to make my own.

It took a couple of iterations on paper, plus one really thin 3D-printed sample, but I did make my own and it works. Here it is in action:

image of a cam gear sprocket holding tool for the Chrysler/Dodge/Plymouth 2.0 and 2.4 liter engine

image of a cam gear sprocket holding tool for the Chrysler/Dodge/Plymouth 2.0 and 2.4 liter engine

And, in case you want to print your own, here is the STL file.

STL file for 3D printing a cam gear holding tool for Chrysler or Dodge 2.0 and 2.4 L engines

Note that it is a very tight fit, so don’t expect it to slide right into the gears. The goal is no gear movement at all, so it needs to be as flush as possible. Be prepared to coerce it into place.

Also note it is about 2 inches deep. The pictures show it only halfway in. Afterwards, I pushed it until it contacted the backstop, and it stuck out just a little bit, enough to still be able to grab the sides.

Therefore, my beloved brethren, be ye steadfast, unmoveable, always abounding in the work of the Lord, forasmuch as ye know that your labour is not in vain in the Lord.

1 Corinthians 15:58

Consistent Interface

One of main complaints with the iPhone is the inconsistent interface for clock notifications. I use both the alarm (for waking up in the morning) and the timer (reminders during the day) just about every day. And I never know which button to press to get it to stop.

Here’s the alarm:

image of an iPhone's alarm screen

And here’s the timer:

image of an iPhone's timer screen

My problem is that I want to press the larger, more colorful button. But Apple has made the decision that for the two parts of its clock app, the larger, more colorful button will have two different meanings.

So when my iPhone starts making clock noises, I have to look at it, figure out which button means “stop” and which button means “remind me again soon”, and press the one I want.

One of these days, I’ll change my alarm setting to turn off the snooze option…

Then when you sound an alarm the second time, the camps that are pitched on the south side shall set out; an alarm is to be sounded for them to break camp.

Numbers 10:6

iPhone Repair Woes

Note: see the bottom of this post for the lesson.

The battery in Some Wife’s iPhone was getting old, and it no longer could get her through the day without needing to be recharged. The battery health-o-meter indicated it was not so healthy anymore, confirming with numbers what we already knew.

So, having replaced batteries in iPhones of generation 4, 5, 6, and 7, I figured I could handle an iPhone 10. Excuse me, iPhone X.

I looked at the repair instructions, and they looked about the same as before, so I ordered a new battery.

The instructions say to take apart the iPhone in the usual way – take the screws out, soften the glue, and carefully pry the screen away from the housing.

The instructions emphasize to be extra careful not to pry the screen from its frame, but make sure to pry the screen and frame together away from the housing.

I wondered how to know if I’m prying the screen only (bad) or screen and frame. I found out the hard way.

I thought the screen came away a little too easily, and after I had separated about 3/4 of it, that’s when part of the frame came away from the housing and I saw the difference.

It turns out I had been doing the bad thing and separating the screen from itself.

Argh.

I quickly pried the frame out from the housing and tried to keep the screen and frame together as much as possible. I did end up getting the screen and frame back together, and both off the rest of the phone, but I wondered what effects that might have had.

The rest of the battery replacement procedure went okay, not perfect but it got done.

In the course of previous battery replacements, I have learned to turn the phone on after everything is connected but before I screw it back together. One of my earlier attempts I had mis-connected something, so I had to take it back apart and re-fix it. It saves time and effort to test it slightly earlier in the process, rather than waiting until the very end.

So that’s what I did with this phone. After I had all the electrical connections back together, but the screen not in place, I turned on the phone.

In previous repairs, I saw the Apple logo appear on the screen and I knew everything was fine, so then I’d turn the phone back off, screw everything down, and then turn it on and then I could be done.

But with this phone, when I turned it on, the screen was blank. No change. But the phone made noises that told me it was on, which lead me to conclude that I broke the screen during the repair process.

Now the problem was that this was Some Wife’s phone, and both she and I were expecting the repair to be done that evening. That was not a fun thing to do – come back into the room and break the news to her that she no longer has a functioning phone.

But she took it in stride, and we came up with a backup plan to borrow Alpha’s backup phone (an iPhone 7) that he no longer used but still had around. One sim card swap later, and she had a phone. But it had none of her apps and none of her contacts, so it was a challenge over the next couple of days when a text would come in with just a number listed, to see if she could figure out who it was without responding back “who are you?”

Anyway, the day after I broke her phone, I told her “good news, you get to get a new phone”. Or at least new to her. Actual new phones are ridiculously expensive, so we upgraded her to an iPhone 12, which was still more money that I had planned for a simple battery repair, but much better than a phone that costs as much as my car did.

In the meantime, before we settled on which exact phone, I ordered a replacement screen for the iPhone X. She wanted to be able to get a bunch of info off the old phone, and it was cheaper than a used iPhone X, so we’d still come out ahead by having an iPhone X with a new battery.

I thought I had turned off the broken phone, but I found out it was on when one of her alarms went off. The touch part of the screen was working fine, but I couldn’t see where to turn off the alarm, so I tapped a couple of times where the Stop button should have been and got it to turn off.

The replacement screen came in about the same time as her newer phone, so while she was setting up the phone, I was trying to get the screen working on the old one.

The repair went smoothly, except when everything was connected, I turned on the phone, and it didn’t work. I disconnected the cables and put them together again. Still nothing.

I thought I must have damaged a connector or something in the process. With nothing else left to try, I decided to just put everything back together and wait until tomorrow to figure out what to do.

After I put the screen fully in place and screwed it down, it worked.

At first I was excited and relieved. But then it got me thinking, and I bet there was nothing wrong with the old screen. I could have tested it by taking the new screen off and putting the old one back on, but at that point I didn’t want to mess with anything. But I’m about 80% confident it would have worked.

Lesson for iPhone Battery Replacements
From what I can tell, the new style (and I don’t know when it changed, but somewhere between iPhone 7 and X) is to have grounding pads for the screen be separate contacts at the bottom of the screen, not in the cable connector. So the screen isn’t fully electrically connected until it is fully physically installed. So you cannot test the repairs with the screen slightly off the phone, even just a little bit.
